Attributes
| Ssp Category | npt-thread-tee-trufit |
|---|---|
| Ssp Subcategory | branch-tee-trufit |
| Part Number | imt4bt-1 |
Description
TruFit Pipe Fittings, , Branch Tee, 1/4-18 FNPT x 1/4-18 FNPT x 1/4-18 MNPT, Alloy 400
Specifications
| Body Material | Alloy 400 |
|---|---|
| Connection 1 - Type | Female National Pipe Thread |
| Connection 1 - Size | 1/4-18 |
| Connection 2 - Type | Female National Pipe Thread |
| Connection 2 - Size | 1/4-18 |
| Connection 3 - Type | Male National Pipe Thread |
| Connection 3 - Size | 1/4-18 |
| Brand Series | TruFit |
| Shape | Tee |
| End Connections | FNPT x FNPT x MNPT |
| Production Category | 4 |
| End Connection Type | Female National Pipe Thread by Male National Pipe Thread |
| A | 1.76 in |
| E | 0.26 in |
| H | 3/4 in |
| P | 1/4 in |
| L | 0.88 in |
| S | 1.09 in |
