Attributes
| Ssp Category | sae-100r2-type-a-din20022-type-1st-hose-fittings |
|---|---|
| Ssp Subcategory | sae-100r2a-x-male-pipe-connector-field-attachable- |
| Part Number | ah40720-16-16-m |
Description
Field Attachable Male Pipe Connector, 1-11 1/2 MNPT x 1 SAE 100R2, Alloy 400
Specifications
| Body Material | Alloy 400 |
|---|---|
| Connection 1 - Type | Male National Pipe Thread |
| Connection 1 - Size | 1-11 1/2 |
| Connection 2 - Type | SAE 100R2 TYPE A |
| Connection 2 - Size | 1 in |
| Brand Series | Field Attachable |
| Shape | Straight |
| Hose ID | 1 in |
| End Connections | MNPT x SAE 100R2 |
| Production Category | 4 |
| End Connection Type | 2pc Hose Ftg SAE 100R2 by Male National Pipe Thread |
| T | 1-11 1/2 |
| L | 4.37 in |
| L1 | 2.36 in |
| Nipple ID | 0.82 in |
| W Hex | 1 3/8 in |
| W1 Hex | 1 3/4 in |
